RGB LED strip lights can completely change the feel of a space without requiring a major makeover. With different colors, brightness levels, and lighting modes, they give you plenty of room to get creative.
Lamomo’s RGB LED strip lights come in two models, with different sizes, cutting intervals, and power requirements.
This guide covers how to install LED strip lights, from cutting and connecting the strip to setting up and using both options.
Tools You’ll Need
Cutting and installing RGB LED strip lights involves a few basic tools. Having them ready beforehand makes the process much smoother.
Have ready:
- Sharp scissors for cutting along the marked points
- A utility knife for exposing the copper pads
- A soldering iron and solder for connecting cut sections
- 20 AWG two-core cable for linking sections
- Silicone glue and waterproof caps for sealing connections
- Mounting clips, screws, and suitable anchors for installation
How To Cut and Connect RGB LED Strip Lights
Firstly, measure the area you want to cover and find the nearest black cutting mark on your strip. You should also test the strip first, then disconnect it from the power source before cutting.
- Use sharp scissors to cut the strip directly along the marked point. For different sizes of LED strip lights, please refer to the corresponding product’s detailed specification sheet for the cutting distance.
For the 6mm × 12mm RGB model, 16.4Ft cut every 0.98 in / 2.5 cm.
For the 8mm × 16mm RGB model, cut every 2.36 in / 6 cm. - If you’re unsure about the length, leave the strip slightly longer rather than cutting it too short.
- Never cut outside the black cutting marks, as doing so can damage the circuit and cause part of the strip to stop working.
Connecting Cut Sections
If you ever need to join two cut sections to reach the desired length, you can connect them using the soldering method.
- Use a utility knife to carefully peel back about 1/8 inch of the silicone coating and expose the copper pads.
- Tin the exposed pads and wire ends with solder.
- Match the polarity, then solder the wires to the corresponding pads.
- Slide the waterproof cap over the connection and seal it with silicone glue for outdoor or humid installations.
- Test the strip again before moving on to installation.
How To Install RGB LED Strip Lights
Both Lamomo RGB LED strip light models use mounting clips and screws rather than adhesive backing. Plan the route first, then mark where you want the clips to go.
- Position the mounting clips along the planned route.
- Secure the clips with screws. For brick, concrete, or wooden surfaces, use pilot holes and suitable wall anchors where needed.
- Snap the LED strip into the clips and make sure it sits securely.
- Connect the setup in this order: LED strip → controller → power supply → outlet.
- The 6mm × 12mm model requires a 12V DC 5A power adapter, which isn’t included. The 8mm × 16mm model comes with a 24V DC power adapter.
- For outdoor installations, keep the power adapter and connection points protected or indoors if possible. Note that the adapters themselves are not waterproof.
- Use a power supply with the correct voltage and wattage for the strips. Lamomo recommends leaving a 20% to 30% wattage margin to help prevent overload.
How To Use Lamomo RGB LED Strip Lights
Once you’ve installed your RGB LED strip lights, there are several ways to customize the lighting to suit your space. Both Lamomo models offer multiple colors, brightness levels, and lighting modes, while their sizes make them suitable for different applications.
Where To Use Them
- The 6mm × 12mm model works well in bedrooms, kitchens, RVs, gaming setups, bars, small outdoor spaces, and compact custom shapes.
- The 8mm × 16mm model is better suited to larger rooms, house exteriors, yards, offices, RV exteriors, fences, windows, staircases, and longer installations.
RGB Lighting Features
Both models let you adjust the brightness from 10% to 100% and choose from several lighting options.
- Static colors for a consistent look
- Scene modes for preset lighting effects
- Music mode to sync the lights with sound
- Timer function for scheduled lighting
- Remote control for quick adjustments
- App control through your smartphone
- Voice control with Alexa and Google Assistant
Setting Up App Control
To control the lights through the app, start by turning on Bluetooth on your phone and powering the controller and LED strip lights. If the controller needs to be reset, hold the switch button for 10 seconds. Once the controller is ready, open the Smart Life app and tap the “+” sign to add the device when it appears. After the connection is complete, you can use the app to adjust the color, brightness, lighting modes, timing, and power.
FAQ
1. Why are my LED strip lights flickering?
Flickering or dimming can happen when the power supply doesn’t provide enough wattage for the LED strip lights. Using a power supply with a 20% to 30% wattage margin can help prevent this issue.
2. Can you cut LED strip lights to fit around a corner?
Yes. You can cut the strip to fit around a corner, as long as the cut is made at a designated cutting mark.
3. Are RGB LED strip lights waterproof?
Lamomo’s RGB LED strip lights have an IP65 rating, making the strips suitable for outdoor and wet-area use. However, the power adapters and connection points aren’t waterproof and should be protected from moisture.
4. Is the Smart Life app available on iPhone and Android?
Yes. The Smart Life app is available on both the App Store and Google Play, so you can use it with a compatible iPhone or Android phone to control your RGB LED strip lights.
Conclusion
RGB LED strip lights give you plenty of room to get creative with color, brightness, and different lighting effects. With the right setup, you can create lighting that not only fits your space but also adds personality to it.
You can also browse Lamomo’s other LED lighting options to find something that suits your next project.
